Key Features & Benefits – EPMAN weld-on aluminum fuel filler neck, black, 3.0" (76mm)
The EPMAN weld-on aluminum fuel filler neck, black, 3.0" (76mm) is made to be welded into a tank wall so you can place the fill point where your layout needs it. It can be used on custom fuel tanks, water tanks, coolant reservoirs, and other fabricated metal tanks.
The body is 6061-T6 aluminum, sealed by a screw cap with a sealing ring. The cap has a knurled edge for grip, and the unit is a non-vented design.
When is this useful?
It suits builds where you want a compact weld-in fill point with a sealed cap, while matching the 3.0" (76mm) size to your hose/tube routing and packaging around the cap.
Technical specs
- Product code: EPYXG200M30BK
- Material: 6061-T6 aluminum
- Design: weld-on filler neck, screw cap, sealing ring
- Type: non-vented
- Color: black cap
- Size option: 3.0" (76mm)
Selection & installation tips
- Hose/tube match: Match the 3.0" (76mm) size to your hose/tube diameter and clamp range.
- Packaging: Check clearance around the cap so it remains easy to open in the installed position.
- Venting plan: Because it is non-vented, plan tank venting separately within your system design.
- Material & process: Ensure the receiving tank material and welding process are compatible with aluminum.
- Fit-up: Test-fit the neck orientation so routing does not preload the weld and the cap stays accessible.
Before welding, verify your hose/tube sizing, cap clearance, and venting strategy, then match them to the selected 3.0" (76mm) size option.
