Epman 2.75-Inch 70 mm Red Intercooler Quick-Release Clamp Kit with Bolt Fastening
The Epman 2.75-inch red intercooler quick-release clamp kit includes a solid billet 6061 aluminum clamp, two weld-on aluminum ferrules and a double O-ring seal. Its two-bolt fastening creates a removable pipe joint, while the connection permits angular, axial and radial movement.
Key Features & Benefits – Epman 2.75-inch red intercooler quick-release clamp kit
The Epman 2.75-inch red intercooler quick-release clamp kit provides a weld-on connection with a double O-ring seal for custom charge-pipe systems. The 70 mm (2.75-inch) internal size is intended for this pipe size, and the two aluminum ferrules must be welded to the pipe ends.
The clamp body is made from solid billet 6061 aluminum and has a red anodized finish. Its design permits angular, axial and radial movement, helping to isolate vibrating pipe sections compared with a completely rigid joint.
When is this useful?
The kit can be used to create a removable connection in custom turbo and intercooler piping where sealing and later disassembly are important. Loosening the two fastening bolts allows the outer clamp to be removed, while the double O-ring arrangement supports a sealed, vibration-isolating connection.
Technical specs
- Part number: EPKKA70-RD
- Product type: weld-on intercooler quick-release clamp kit
- Internal size: 2.75 inches, 70 mm
- Clamp material: solid billet 6061 aluminum
- Colour and finish: red anodized
- Kit contents: aluminum clamp, two weld-on aluminum ferrules and O-rings
- Fastening: two-bolt removable clamp body
- Burst pressure rating: 800 psi, 55.2 bar
- Temperature resistance: up to 400°F, 204°C
- Permitted movement: angular, axial and radial
Selection & installation tips
- Pipe size: measure the actual pipe diameter and test-fit the 70 mm ferrules before welding.
- Pipe material: the supplied ferrules are aluminum, so the pipe and welding process must be suitable for aluminum fabrication.
- O-rings: remove the seals before welding and reinstall them only after the components have fully cooled and been cleaned.
- Alignment: deburr the pipe ends and align both ferrules concentrically without preload before completing the welds.
- Access: retain sufficient installation clearance for loosening both bolts and removing the outer clamp.
Before installation, verify the actual pipe dimensions, compatibility between the pipe and weld-on ferrules, the condition of the O-rings and access to both bolts, then compare these points with the listed technical details.
Net price: 15 €
