AN10 Stainless Steel Braided High-Pressure Hose – Synthetic Nitrile Inner Tube with Partial Reinforcement

This AN10 high-pressure rubber hose features a synthetic-nitrile inner tube with a partial stainless steel reinforcement braid, covered by a heavy-duty full stainless steel outer braid. This construction ensures excellent flexibility, durability, and resistance to abrasion, making it ideal for extreme applications.

Key Specifications:

• Working Pressure: 1000 psi (69 bar)
• Burst Pressure: 6000 psi (408 bar)
• Inner Diameter: 14.27 mm
• Outer Diameter: 20.24 mm
• Temperature Range: -40°F to 257°F (-40°C to +125°C)

Applications:

• Fuel supply and return lines
• Motor oil and power steering fluid transport
• Coolant and air systems

Price listed is for 1 meter, with custom lengths available. Not suitable for E85 fuels; for such applications, PTFE hoses are recommended.
