Key Features & Benefits – AN10 90 degree hose end fitting
The AN10 90 degree hose end fitting is a 90° aluminum fitting that helps route lines with a tighter turn and improved clearance in compact engine bays. For functional compatibility, it is intended for Dash 10 (AN10) setups and braided reinforced rubber hose applications.
The blue/red finish makes the fitting easy to identify during assembly and service. It can be used on oil, fuel, or air line routing where a 90° direction change is practical, provided the hose type and actual line dimensions match your build.
When is this useful?
This is useful when you need a 90° turn on an AN10 line and want to route the hose neatly without stressing the run or forcing sharp bends.
Technical specs
- Size: Dash 10 (AN10)
- Type: 90 degree
- Material: aluminum
- Color: blue/red
- Recommended hose type: braided reinforced rubber hose
- Brand: LLRacing
Selection & installation tips
- Confirm sizing: verify your system is truly Dash 10 (AN10) across hoses and fittings.
- Match the hose type: confirm you are using braided reinforced rubber hose and that the fitting style matches the hose construction.
- Plan clearance: test the 90° orientation so the hose does not rub on moving parts or sit too close to hot components.
- Prepare the hose end: cut the hose square, clean the end, and keep debris out of the joint during assembly.
- Final check: after assembly, verify the connection is stable and the hose run is not twisted or side-loaded.
Before installation, compare the AN10 (Dash 10) size, your hose type, and the clearance needed for a 90° turn against the technical specs listed above, then verify the fit on your specific routing.
