Key Features & Benefits – AN10 60 degree hose end fitting
The AN10 60 degree hose end fitting is a 60° hose end in a swivel design, helping you route AN10 lines with cleaner direction changes and easier alignment during assembly. For functional compatibility, it is intended for AN10 (Dash 10) systems and use with braided reinforced rubber hose.
It is made from anodized aluminum with a blue/red finish, and it is described as compatible with common industry standards such as Earls, Speedflow, Aeroquip, and Goodridge. Suitable for oil, fuel, and air line routing where an industry-standard sealing concept is used.
When is this useful?
This is useful when you need a 60° direction change on an AN10 line and the swivel style helps you set the final orientation more easily in tighter packaging areas.
Technical specs
- Size: AN10 (Dash 10)
- Angle: 60°
- Design: swivel
- Material: anodized aluminum
- Color: blue / red
- Use: oil, fuel, and air systems
- Compatibility: braided reinforced rubber hose
- Sealing system: industry standard (motorsport compatible)
- Brand: LLRacing
Selection & installation tips
- Confirm sizing: verify your system is consistently AN10 (Dash 10) across hoses and fittings.
- Match the hose type: this style is intended for braided reinforced rubber hose, so confirm the hose construction matches the fitting type.
- Cut & cleanliness: make a square cut, clean the hose end, and keep debris out of the joint during assembly.
- Swivel alignment: set the final orientation so the hose run is not twisted and the fitting is not side-loaded by the routing.
- Clearance & heat: allow for engine movement and keep the line away from hot, sharp, or moving parts.
Before installation, compare the AN10 (Dash 10) size, hose construction, and the clearance needed for a 60° turn with the technical specs listed above, then verify the fit on your specific routing.
