Connecting rods do not include bolts!
TurboWorks forged connecting rods for 1.6 16V TU5J4 engine, mounted in PEUGEOT 106 GTI, CITROEN SAXO.
The set does not contain assembly screws and grease. You can buy them separately, after choosing an option from the drop-down menu above the price of the product.
| Center to Center Length | Big End Bore | Big End Width | Small End Bore | Small End Width |
| 137.75mm | 48.66mm | 24mm | 19.46mm | 24mm |
Connecting rods designed in H-Beam technology, allow to transfer power exceeding 200 HP / Cylinder.
They are made of the highest quality forged AISI 4340 steel (En24). Hardness HRC 35-38.
All forgings are degassed and X-rayed to detect all potential material defects.
Then, they undergo heat treatment, sliding and honing to achieve high strength and maximum accuracy.
