Inline Brake Servo Non Return Check Valve One-Way (4mm)
4 mm check valve for vacuum hose lines, one-way flow to reduce backflow, transparent body for quick visual checks, PVED plastic connector housing, compact inline design for vacuum and pneumatic systems.
Net price: 2 €
Key Features & Benefits – 4 mm vacuum hose check valve
The 4 mm vacuum hose check valve (vacuum check valve) is an inline valve designed to support one-way flow and help prevent liquid and gas backflow. It is intended for 4 mm vacuum hose connections.
The transparent design helps with quick inspection after installation. The connector is made from PVED plastic, and the valve can be used in vacuum systems such as brake booster circuits and other pneumatic applications.
When is this useful?
It is useful when a vacuum or pneumatic branch needs stable directional behaviour and you want to reduce the chance of reverse flow affecting system operation.
Technical specs
- Product type: Check valve for vacuum hose
- Size: 4 mm
- Material: PVED plastic
- Colour: Transparent
- Function: Prevents liquid and gas backflow
- Compatibility: Water; gas; air; exhaust systems
- Part number: EPCGQ230DXF
Selection & installation tips
- Hose size: Confirm your hose size matches 4 mm and the hose sits tightly on the barb.
- Flow direction: Install it in the correct one-way direction and mark the line if future service is expected.
- Retention: In high-vibration areas, use suitable clamps/retainers so the hose cannot creep or loosen.
- Placement: Position it to avoid hose kinks and to keep access for inspection and servicing.
- Functional check: After installation, verify the system behaves as intended and there are no leaks at the connections.
Before installation, verify 4 mm hose fit, flow direction, and placement, then match them to the technical specs above for correct integration.
